Vertical Cable 107-2319/P/WH RG59 Siamese Coaxial Cable, Plenum, Bare Copper Conductor, 95% CCA Braid, with 18/2 AWG Power
RG59 1000 Foot Plenum Siamese Cable 20 AWG with 18 AWG Power, White. Commonly used in audio/video, radio frequency, and CCTV transmissions.
This RG59 Siamese Bulk Cable features a 95% braid, unshielded 18 AWG stranded pair power cables and gas-injected foam polyethylene insulation. This bulk cable comes in a white in-wall rated PVC jacket with convenient length markings and in a 500-foot spool.
Plenum (CMP) Rated PVC Jacket
Plenum rated Siamese cable contains a flame retardant PVC jacket and is designed for cable runs being laid in spaces defined as "Air Plenums", this includes raised flooring systems, air handling ducts, etc. Plenum jackets produce less smoke than traditional PVC jackets.
Siamese Cable Design
95% Solid Bare Copper & 2 Conductor Electrical Cable, Siamese Cable is a type of Combination Cable designed to make running multiple cables much easier, especially jobs where two separate types of cable a required (usually power and data or video). Typically used for Security or CCTV (closed circuit) installations.
This type of cable contains a coax cable with 95% CCA braid and a power wire. RG59 cable is designed to carry signals operating below 50Mhz and cable runs at 100ft or less.
For this particular cable, the gauge is 20 AWG, which is a diameter of about 0.0320 Inches, or 0.812mm. American Wire Guage (AWG) is the standardized gauging system for measuring wire sizes.
For this particular cable, the gauge is 18 AWG, which is a diameter of about 0.0403 Inches, or 1.024mm. American Wire Guage (AWG) is the standardized gauging system for measuring wire sizes.
