Nitrotel Cat6e RJ45 Keystone Jack Module, 90 Degrees – UTP

SKU#: NTKJ6EBUSL

UPC#: 787790094609

60 Day Money Back Guarantee

100% Secure Shopping

SKU#: NTKJ6EBUSL

UPC#:787790094609
$3.22

SKU#: NTKJ6EBUSL

UPC#:787790094609
Color:
Blue

Same Day Shipping likely on orders placed in the next 00 hours 00 minutes 00 seconds.

Local Pickup May Be Available in Concord, North Carolina for more information..

Califonia Warning 65

California Prop 65 Warning

×
For CA Residents Only.
California Proposition 65 Warning

Proposition 65, officially the Safe Drinking Water and Toxic Enforcement Act of 1986, is a law that requires warnings be provided to California consumers when they might be exposed to chemicals identified by California as causing cancer or reproductive toxicity. The warnings are intended to help California consumers make informed decisions about their exposures to these chemicals from the products they use. The California Office of Environmental Health Hazard Assessment (OEHHA) administers the Proposition 65 program and publishes the listed chemicals, which includes more that 850 chemicals. In August 2016, OEHHA adopted new regulations, effective on August 30, 2018, which change the information required in Proposition 65 warnings.

• WARNING: Some cable, plastic, and metal products may contain chemicals known to the state of CA to cause cancer, birth defects, or other reproductive harm.

For further information, please visit www.P65Warnings.ca.gov

  • Description+
  • Nitrotel Cat6 RJ45 Keystone Jack Module, 90 Degrees – UTP

    Nitrotel Cat6E Keystone Jacks offer exceptional interconnection in 10/100/1000 Base-T Fast and Gigabit Ethernet applications. These component-rated keystone jacks work together with high speed cables, cores and panels to provide performance beyond proposed category 6 standards. Their compact design allows them to ?t into any conventional face plate, outlet box, or panel.

  • Features+
    • Backward compatible
    • Compliant with EIA/TIA-568.2-D Cat6 connecting hardware specifications
    • PoE Compliance: Supports IEEE 802.3f/ 802.3at /802.3bt at PoE++ applications and Supports Power over HDBaseT™ (PoH) up to 100 watts
    • Dual-color coded labeling made for both 568A & 568B wiring schemes
    • Compact slim design fits into any conventional face plate, outlet box, or panel
    • UL 1863 approved
    • Patented Printed Circuit Board designed to meet Cat6 performances
    • Utilizes 90 degree industry standard 110 termination style
    • 50u” gold plated contacts.
    • Enhanced IDC termination towers reduce installation time and increased performance
  • Specs+
  • Performance: Specifications:
    Cat6 250 MHz +
    Compliance Meets EIA/TIA-568.2-D transmission performance specifications and ISO 11801 Class E channel and component requirements at swept frequencies up to 250 MHz.
    IDC: Specifications:
    Housing PC UL 94
    Type 110 Punchdown, 90 degrees
    Contact Construction Phosphor bronze with tin plated
    Operating Life 200 re-terminations (min.)
    Cabling 22-26 AWG, Stranded and Solid UTP cable
    Electrical: Specifications:
    Wiring for T568A or T568B
    Dielectric Withstand 1000 VAC RMS @ 60Hz
    Voltage/current 150 VDC @ 1.5A, max., > 100mW @ 500 Vdc
    RJ45 Connector: Specifications:
    Contact Construction Phosphor bronze, 50μ in. gold plating
    Insertion Life 750 insertions, min., @ < 0.2 dB of insertion loss
    Insertion Force 900 gms for 8 contacts
    Retention Strength 7,7 Kgs between Jack and Plug
    Housing High-impact thermoplastic, UL94V-0 rated
  • Reviews+
  • Nitrotel Cat6 RJ45 Keystone Jack Module, 90 Degrees – UTP

    Nitrotel Cat6E Keystone Jacks offer exceptional interconnection in 10/100/1000 Base-T Fast and Gigabit Ethernet applications. These component-rated keystone jacks work together with high speed cables, cores and panels to provide performance beyond proposed category 6 standards. Their compact design allows them to ?t into any conventional face plate, outlet box, or panel.

    • Backward compatible
    • Compliant with EIA/TIA-568.2-D Cat6 connecting hardware specifications
    • PoE Compliance: Supports IEEE 802.3f/ 802.3at /802.3bt at PoE++ applications and Supports Power over HDBaseT™ (PoH) up to 100 watts
    • Dual-color coded labeling made for both 568A & 568B wiring schemes
    • Compact slim design fits into any conventional face plate, outlet box, or panel
    • UL 1863 approved
    • Patented Printed Circuit Board designed to meet Cat6 performances
    • Utilizes 90 degree industry standard 110 termination style
    • 50u” gold plated contacts.
    • Enhanced IDC termination towers reduce installation time and increased performance
    Performance: Specifications:
    Cat6 250 MHz +
    Compliance Meets EIA/TIA-568.2-D transmission performance specifications and ISO 11801 Class E channel and component requirements at swept frequencies up to 250 MHz.
    IDC: Specifications:
    Housing PC UL 94
    Type 110 Punchdown, 90 degrees
    Contact Construction Phosphor bronze with tin plated
    Operating Life 200 re-terminations (min.)
    Cabling 22-26 AWG, Stranded and Solid UTP cable
    Electrical: Specifications:
    Wiring for T568A or T568B
    Dielectric Withstand 1000 VAC RMS @ 60Hz
    Voltage/current 150 VDC @ 1.5A, max., > 100mW @ 500 Vdc
    RJ45 Connector: Specifications:
    Contact Construction Phosphor bronze, 50μ in. gold plating
    Insertion Life 750 insertions, min., @ < 0.2 dB of insertion loss
    Insertion Force 900 gms for 8 contacts
    Retention Strength 7,7 Kgs between Jack and Plug
    Housing High-impact thermoplastic, UL94V-0 rated
