BZBGEAR Full HD Integrated SDI 20X Zoom Camera with Audio input

SKU#: BG-B20SA

UPC#: 850023208255

60 Day Money Back Guarantee

100% Secure Shopping

5-year-warranty5

5 Year Warranty

SKU#: BG-B20SA

UPC#:850023208255
$849.00

SKU#: BG-B20SA

UPC#:850023208255

SKU#: BG-B20SA

UPC#: 850023208255

60 Day Money Back Guarantee

100% Secure Shopping

5-year-warranty5

5 Year Warranty

Same Day Shipping likely on orders placed in the next 00 hours 00 minutes 00 seconds.

  • Description+
  • BZBGEAR BG-B20SA high-quality remote camera features 1080P/60Hz imaging with 20X optical (10X digital) zoom lens. It offers the flexibility of 3G SDI/HDMI simultaneous outputs with crystal clear Uncompressed HD images up to 1080P at 60fps. It’s compact overall size makes it perfect for installations that require a clean, discreet appearance. Designed for fixed angle video monitoring, it is ideal for hallways, lobbies, interview rooms, and warehouses. The BG-B20SA camera can provide the H.264 / H.265 / MJPEG compressed video signal, as well as the RTMP protocol for broadcasting to Facebook and YouTube via an RJ-45 connection.

  • Features+
    • Full HD output delivers crystal clear video
    • IP Enabled: Adjust settings and stream over LAN
    • SDI Output Perfect for long distance runs using coaxial cable
    • External Audio Input to Add a microphone or other audio source
    • Works great for Lecture halls, studios, surveillance and more
  • Specs+
  • Camera Parameters
    Sensor 1/2.8 inch high quality HD CMOS sensor
    Effective Pixels 16:9, 2.07 megapixel
    Video Format 1080P60/50/30/25/59.94/29.97
    1080I60/50/59.94
    720P60/50/30/25 /59.94/29.97
    Optical Zoom 20X optical zoom, f?5.2~98mm
    View Angle 5.5°(tele) - 54.7°(wide)
    Aperture F1.6 ~ F3.5
    Digital Zoom 10X
    Minimum Illumination 0.5Lux (F1.8, AGC ON)
    DNR 2D & 3D DNR
    White Balance Auto / Manual/ One Push/ 3000K / 4000K / 5000K / 6500K
    Focus Auto/Manual
    Aperture Auto/Manual
    Electronic Shutter Auto/Manual
    BLC ON/OFF
    WDR OFF/ Dynamic level adjustment
    Video adjustment Brightness, Color, Saturation, Contrast, Sharpness, B/W mode, Gamma curve
    SNR >55dB
    Input/output Interface
    Video Interfaces Audio In, 3G-SDI
    Image Code Stream Dual stream output
    Video Compression Format H.264, H.265
    Control Protocol Protocol: VISCA / Pelco-D / Pelco-P Baud Rate: 115200/9600/4800/2400bps
    HD IP Interface 100M IP port (10/100BASE-TX), Support Visca protocol control through IP port.
    Network Protocol RTSP/RTMP, ONVIF
    Power Interface 5.0 Card line socket (DC12V)
    Other Parameters
    Power Adaptor AC110V-AC220V to DC12V/1A
    Input Voltage DC12V±10%
    Input Current 400mA(Max)
    Consumption 4.8W (Max)
    Store Temperature -10°C ~ +60°C
    Store Humidity 20% – 95%
    Working Temperature -10°C ~ +50°C
    Working Humidity 20%–80%
    Dimension 155.7mmX70mmX70mm
    Weight 0.7KG
    Application Indoor
    Remote Operation (IP) Remote Upgrade, Reboot and Reset
  • Package Contents+
    • 1x BG-B20SA Camera
    • 1x 12V/1A Power Supply
    • 1x User’s Manual
  • Reviews+
  • BZBGEAR BG-B20SA high-quality remote camera features 1080P/60Hz imaging with 20X optical (10X digital) zoom lens. It offers the flexibility of 3G SDI/HDMI simultaneous outputs with crystal clear Uncompressed HD images up to 1080P at 60fps. It’s compact overall size makes it perfect for installations that require a clean, discreet appearance. Designed for fixed angle video monitoring, it is ideal for hallways, lobbies, interview rooms, and warehouses. The BG-B20SA camera can provide the H.264 / H.265 / MJPEG compressed video signal, as well as the RTMP protocol for broadcasting to Facebook and YouTube via an RJ-45 connection.

    • Full HD output delivers crystal clear video
    • IP Enabled: Adjust settings and stream over LAN
    • SDI Output Perfect for long distance runs using coaxial cable
    • External Audio Input to Add a microphone or other audio source
    • Works great for Lecture halls, studios, surveillance and more
    Camera Parameters
    Sensor 1/2.8 inch high quality HD CMOS sensor
    Effective Pixels 16:9, 2.07 megapixel
    Video Format 1080P60/50/30/25/59.94/29.97
    1080I60/50/59.94
    720P60/50/30/25 /59.94/29.97
    Optical Zoom 20X optical zoom, f?5.2~98mm
    View Angle 5.5°(tele) - 54.7°(wide)
    Aperture F1.6 ~ F3.5
    Digital Zoom 10X
    Minimum Illumination 0.5Lux (F1.8, AGC ON)
    DNR 2D & 3D DNR
    White Balance Auto / Manual/ One Push/ 3000K / 4000K / 5000K / 6500K
    Focus Auto/Manual
    Aperture Auto/Manual
    Electronic Shutter Auto/Manual
    BLC ON/OFF
    WDR OFF/ Dynamic level adjustment
    Video adjustment Brightness, Color, Saturation, Contrast, Sharpness, B/W mode, Gamma curve
    SNR >55dB
    Input/output Interface
    Video Interfaces Audio In, 3G-SDI
    Image Code Stream Dual stream output
    Video Compression Format H.264, H.265
    Control Protocol Protocol: VISCA / Pelco-D / Pelco-P Baud Rate: 115200/9600/4800/2400bps
    HD IP Interface 100M IP port (10/100BASE-TX), Support Visca protocol control through IP port.
    Network Protocol RTSP/RTMP, ONVIF
    Power Interface 5.0 Card line socket (DC12V)
    Other Parameters
    Power Adaptor AC110V-AC220V to DC12V/1A
    Input Voltage DC12V±10%
    Input Current 400mA(Max)
    Consumption 4.8W (Max)
    Store Temperature -10°C ~ +60°C
    Store Humidity 20% – 95%
    Working Temperature -10°C ~ +50°C
    Working Humidity 20%–80%
    Dimension 155.7mmX70mmX70mm
    Weight 0.7KG
    Application Indoor
    Remote Operation (IP) Remote Upgrade, Reboot and Reset
    • 1x BG-B20SA Camera
    • 1x 12V/1A Power Supply
    • 1x User’s Manual
