UL Listed

Cat8 RJ45 Connectors - Less Shielded

CAT8 RJ45 connectors are designed to work specifically with Cat.8 Cable. The RJ45 contacts are gold plated, wire alignment insert provides an efficient termination without any need of tools. We do recommend to use a cable striper to expose the inner conductors. The housing of the connectors is fully shielded to avoid corrosion and to protect from EMI (ElectroMagnetic interference).

Choose the Right RJ45 Connectors

Leverage the power of 40G with shielded termination plugs. Your data network is only as strong as your weakest link, so if you're using CAT8 Ethernet cable, make sure you have the correct plugs for the job.

The shielded CAT8 field termination plug is designed specifically for CAT8 bulk cable. This 8 pin 8 conductor (8p8c) plug has 50 micro inch gold plated contacts for superior signal conductivity. The wire alignment insert provides an efficient termination without a crimp tool, although a cable stripper is recommended to prepare the cable for termination. This connector has been rated for PoE and is capable of power transfer.

Why Shield Your RJ45 Connectors?

This connector housing is shielded with zinc die-cast nickel plating. This makes our CAT8 plugs more durable while being less prone to corrosion and rust. All our CAT8 plugs come standard with two different sizes of boots. These boots provide better stress relief support around the connection point of the cable and connector.

The copper foil included with the RJ45 connector will also further shield from any unwanted EMI or crosstalk. So, update your system today so your company can get faster, more efficient conversion rates.

ABA Elite Cat8 RJ45 Field Termination Plug 24 Pack

The ABA Elite Cat8 RJ45 field termination plug makes terminating category 8 cable easier than ever. Save time on your installs with these durable shielded plugs. These are fully compatible with Cat7A or Cat8 riser (CMR) and plenum (CMP) cables, making these a perfect solution if you are wanting to future-proof your network for years to come. Protect your connections from electromagnetic interference (EMI) with these plugs. The tool-less design makes for an efficient connection and punch down. Whether for your home, office, or business, you can trust on these field plugs to boost performance up to 40Gb.

ProSeries Cat6/6a Unshielded Pass-Through RJ45 Modular Plugs with Cap45® 100 pc/Jar

Simply45® ProSeries hybrid connectors feature the patented Cap45. The ProSeries connector provides the convenience of a pass-through style with the security of a standard modular plug. Simply45® only uses the highest quality materials to ensure reliable results and will greatly reduce truck rollbacks. These connectors are commercially rated and feature a 3-prong style contact designed for all PoE applications, making Simply45® ProSeries the most reliable terminations on the market today.

Simply45® the industry-leading brand for RJ45 modular plug innovation and performance solutions introduces the ProSeries Pass-Through RJ45 Modular Plug, S45-1700P for unshielded LAN cables. This exclusive patented pass-through RJ45 modular plug is a historic breakthrough in “pass-through” RJ45 reliability and performance.

The Simply45® ProSeries introduces the exclusive Cap45® (PATENT 10,811,831 B1). Cap45® is an isolation cap/bar that snaps onto the front of the pass-through RJ45 plug after termination, covering the exposed wire ends. Cap45® prevents electrical shorting in the RJ45 socket due to improperly trimmed wires or device sockets that may not be 100% compliant. With Cap45®, any electrical risks associated with exposed wire ends are now eliminated completely.

Cap45® is a MUST-HAVE for all pass-through RJ45 modular plugs used in commercial and certified system terminations.

ProSeries 10G Cat6a/7/7a Shielded External Ground – Pass-Through RJ45 with Cap45® & Bar45® 50 pc/Jar

Simply45® ProSeries hybrid connectors feature the patented Cap45. The ProSeries connector provides the convenience of a pass-through style with the security of a standard modular plug. Simply45® only uses the highest quality materials to ensure reliable results and will greatly reduce truck rollbacks. These connectors are commercially rated and feature a 3-prong style contact designed for all PoE applications, making Simply45® ProSeries the most reliable terminations on the market today.

 Simply45® the industry-leading brand for RJ45 modular plug innovation and performance solutions introduces the ProSeries Shielded with External Ground Pass-Through RJ45 Modular Plug, S45-1755P. The uniquely designed and patented Simply45® ProSeries S45-1755P simplifies and improves the terminated plug performance for shielded 10G LAN cables. The Simply45® ProSeries S45-1755P Pass-Through RJ45 modular plugs are by far the highest performing, easiest to use, and most cost-effective way to professionally terminate 10G Shielded and other large diameter shielded LAN cables.

The S45-1755P are IEEE 802.3 10GBase-T compliant and are recommended for shielded 10G LAN Cables Cat7a/7/6a with FPE insulated wires, and Large OD Shielded LAN cables with PE insulated wires such as Cat6 STP and Cat6a F/UTP. These plugs include some unique features that simplify the RJ45 10G termination process and improve the terminated plug performance.

Simply45® ProSeries introduces the exclusive Cap45® (PATENT: 10,811,831 B1). Cap45® is an isolation cap/bar that snaps onto the front of the pass-through RJ45 plug after termination, covering the exposed wire ends. Cap45® prevents electrical shorting in the RJ45 socket due to improperly trimmed wires or in device sockets that may not be 100% compliant. With Cap45®, any electrical risks associated with exposed wire ends are now eliminated completely.

Cap45® is a MUST HAVE for all pass-through RJ45 modular plugs used in commercial and certified system terminations.

PROSeries 7.3mm Strain Relief with Locking Pin for all Simpy45® UTP Cat6/Cat6A RJ45, Red Tint – 100pcs/bag

10G Rated RJ45 Toolless Shielded Field Plug, Ultra Slim Design for Cat6/6a/7a Shielded LAN cables, - 1ea/Bag

10G Rated RJ45 Field Plug – Ultra Slim – Fully Shielded 1pc Design for Cat6/6a/7a Shielded LAN cables, Toolless, Re-Usable, ANSI/TIA, ISO/IEC, PoE IEEE 802.3bt

Standard Cat6/6a UTP RJ45 Modular Plugs with Bar45™ , Green Tint - 20pcs/Bag

Simply45 Unshielded Standard WE/SS (8P8C) RJ45 Mod Plugs with Bar45 Load Bar for (Cat6/6a UTP); Solid 23AWG PE Insulated, Wire Conductors 1.05-1.17mm/0.041″-0.046″, Max Cable OD 7.4mm/0.291″, Commercial Rated UL94V0, Green Tint

PROSeries Pass Through Green Tint - Cat6 UTP with Cap45™ - 20pc/Bag

S45-1705P – Simply45® ProSeries Cat6/6a Unshielded Pass-Through RJ45 Modular Plugs w/ Cap45® 500 pc/Jar

Simply45® ProSeries hybrid connectors feature our patented Cap45. The ProSeries connector provides the convenience of a pass-through style with the security of a standard modular plug. Simply45® only uses the highest quality materials to ensure reliable results and will greatly reduce truck rollbacks. Our connectors are commercially rated and feature a 3-prong style contact designed for all PoE applications, making Simply45® ProSeries the most reliable terminations on the market today.

Simply45® ProSeries Unshielded Pass Through RJ45 Modular Plugs with Cap45® for 23AWG Solid (Cat6/6a UTP), Hi/Lo Stagger, Wire Conductors 1.05mm-1.2mm/0.041″-0,047″, Max Cable OD 7.4mm/0.0291″, UL94 V0 Commercial Rated, Red Tint- 500pcs/Plastic Jar

Simply45® the industry-leading brand for RJ45 modular plug innovation and performance solutions introduces our ProSeries Pass-Through RJ45 Modular Plug, S45-1700P for unshielded LAN cables. This exclusive patented pass-through RJ45 modular plug is a historic breakthrough in “pass-through” RJ45 reliability and performance.

The Simply45® ProSeries introduces the exclusive Cap45® (PATENT 10,811,831 B1). Cap45® is an isolation cap/bar that snaps onto the front of the pass-through RJ45 plug after termination, covering the exposed wire ends. Cap45® prevents electrical shorting in the RJ45 socket due to improperly trimmed wires or device sockets that may not be 100% compliant. With Cap45®, any electrical risks associated with exposed wire ends are now eliminated completely.

Cap45® is a MUST-HAVE for all pass-through RJ45 modular plugs used in commercial and certified system terminations.

S45-1605P – Simply45® ProSeries Cat6 Unshielded Pass-Through RJ45 Modular Plugs with Cap45® 500 pc/Jar

Simply45® ProSeries hybrid connectors feature our patented Cap45. The ProSeries connector provides the convenience of a pass-through style with the security of a standard modular plug. Simply45® only uses the highest quality materials to ensure reliable results and will greatly reduce truck rollbacks. Our connectors are commercially rated and feature a 3-prong style contact designed for all PoE applications, making Simply45® ProSeries the most reliable terminations on the market today.

Simply45® is the industry-leading brand for RJ45 modular plug innovation and performance solutions.

The Simply45® ProSeries introduces the exclusive Cap45® (PATENT 10,811,831 B1). Cap45® is an isolation cap/bar that snaps onto the front of the pass-through RJ45 plug after termination, covering the exposed wire ends. Cap45® prevents electrical shorting in the RJ45 socket due to improperly trimmed wires or in device sockets that may not be 100% compliant. With Cap45®, any electrical risks associated with exposed wire ends are now eliminated completely.

Cap45® is a MUST-HAVE for all pass-through RJ45 modular plugs used in commercial and certified system terminations.

S45-1605 – Cat6 Unshielded – Pass Through RJ45 – 500 Plugs

Simply45 Pass Through connectors feature our reengineered connectors designed for the technology used today. Simply45 only uses the highest quality materials to ensure reliable results that will greatly reduce truck roll backs. Our connectors are commercial rated and feature a 3 prong style contact designed for all PoE application making Simply45 the most reliable Pass Through termination on the market today.

S45-1505 – Cat5e Unshielded – Pass Through RJ45 – 500 Plugs

Simply45 Pass Through connectors feature our reengineered connectors designed for the technology used today. Simply45 only uses the highest quality materials to ensure reliable results that will greatly reduce truck roll backs. Our connectors are commercial rated and feature a 3 prong style contact designed for all PoE application making Simply45 the most reliable Pass Through termination on the market today.

ProSeries Cat5e Unshielded Pass-Through RJ45 Modular Plugs with Cap45® 500 pc/Jar

Simply45® ProSeries hybrid connectors feature our patented Cap45. The ProSeries connector provides the convenience of a pass-through style with the security of a standard modular plug. Simply45® only uses the highest quality materials to ensure reliable results and will greatly reduce truck rollbacks. Our connectors are commercially rated and feature a 3-prong style contact designed for all PoE applications, making Simply45® ProSeries the most reliable terminations on the market today.

Simply45® is the industry-leading brand for RJ45 modular plug innovation and performance solutions.

The Simply45® ProSeries introduces the exclusive Cap45® (PATENT 10,811,831 B1). Cap45® is an isolation cap/bar that snaps onto the front of the pass-through RJ45 plug after termination, covering the exposed wire ends. Cap45® prevents electrical shorting in the RJ45 socket due to improperly trimmed wires or device sockets that may not be 100% compliant. With Cap45®, any electrical risks associated with exposed wire ends are now eliminated completely.

Cap45® is a MUST-HAVE for all pass-through RJ45 modular plugs used in commercial and certified system terminations.

PROSeries Milwaukee Packout w/ Foam Insert & Category Cable Termination Kit

Simply45 starter kits are bundles of essential components and tools for professionals. This kit is designed to simplify the process of terminating network cables.

The Milwaukee® PACKOUT™ Modular Storage System is the industry’s most durable and versatile storage system. The PACKOUT™ Tool Case with the Simply45® Customized Foam Insert has an impact-resistant molded base that users can connect with all other PACKOUT™ system components via integrated locking cleats. This durable tool storage box is constructed with impact-resistant polymer and a metal-reinforced locking point so it can withstand harsh job site environments. Our heavy-duty tool case is IP65 rated weather seal protects tools and accessories from rain and other jobsite debris. The Tool Case has a 75-pound weight capacity. Our PACKOUT™ Modular Storage System allows you to customize and build your own storage system to easily transport and organize your tools and accessories.

S45-PSKMP1 – Milwaukee Packout PROSeries Cat5e/6/6a Unshielded Starter Kit – 1ea./Boxed

Simply45 starter kits are bundles of essential components and tools for professionals. This kit is designed to simplify the process of terminating network cables. Our starter kits are a perfect combination of components that can be sent to every job site to ensure that users have all the necessary items to get started with Ethernet or network installations. Depending on your specific needs, you can choose a starter kit that will Cut, Strip & Terminate your category cable requirements.

The Milwaukee® PACKOUT™ Modular Storage System is the industry’s most durable and versatile storage system. The PACKOUT™ Tool Case with the Simply45® Customized Foam Insert has an impact-resistant molded base that users can connect with all other PACKOUT™ system components via integrated locking cleats. This durable tool storage box is constructed with impact-resistant polymer and a metal-reinforced locking point so it can withstand harsh job site environments. Our heavy-duty tool case is IP65 rated weather seal protects tools and accessories from rain and other jobsite debris. The Tool Case has a 75-pound weight capacity. Our PACKOUT™ Modular Storage System allows you to customize and build your own storage system to easily transport and organize your tools and accessories.

Simply45 Strain Reliefs for all S45 Brand STP External Ground - 100pcs/Bag

Simply45® strain relief boots give a finished and professional look to the cable assembly, improving cable management and reducing the chances of accidental disconnections. Strain reliefs prevent excessive bending or twisting of the cable near the connector, reducing the risk of damage to the internal wires and ensuring a longer lifespan for the cable. Simply45® strain reliefs are the same width as the RJ45 connector body and becomes integrated into the RJ45 plug during the crimping process. The extended tab provides a snag proof protection for the locking tab on the plug. Adding strain reliefs is a cost-effective way to ensure the longevity and reliability of your network connections.

The Simply45® S45-B003 is an 8.5mm (0.33”) snagless strain relief for use with larger diameter shielded LAN cables. The S45-B003 is recommended for all Simply45® brand shielded with external ground RJ45 modular plugs. These 8.5mm strain reliefs protect the RJ45 modular plug and extend the useful life of the termination. Simply45® recommends that strain reliefs or boots should be used with all RJ45 terminations.

Simply45® S45-B003 – 8.5mm (0.33”) Snagless Strain Reliefs Features:

For Large Diameter LAN Cables. The Simply45® S45-B003 is designed to work with most large diameter LAN cables. It can work with cable diameters up to 8.5mm (0.33”). We recommend this strain relief/boot for all Shielded with External Ground RJ45 modular plugs. You can also use these strain reliefs with other unshielded large-diameter LAN cables such as Cat6 Shielded and Cat6 Shielded Direct Burial.

Prolongs Life of the Termination. The S45-B003 takes the strain off the terminated plug. When you do not use a strain relief, any contact with the plug or cable puts strain directly on the terminated plug. Over time this could cause one or more of the RJ45 pins to become loose. If a pin becomes loose it will create electrical resistance.  Resistance creates heat. This could then cause performance problems or damage to the device socket.

Fits Over the Terminated RJ45 Modular Plug. The S45-B003 is designed to fit over Simply45® shielded with external ground RJ45 modular plugs.

Maintains Correct Bend Radius of the Termination. The Simply45® S45-B003 Strain Reliefs protect the terminated RJ45 from damage during the life of the link or channel. Maintaining industry standards bend radius is important for maximizing the link/channel performance.

Professional Finish. In addition to protecting the termination and extending the operating life of the link/channel, the S45-B003 strain reliefs also provide a professional finish to your terminated RJ45.

Trimmable. The S45-B003 strain reliefs are trimmable so that you can adjust the bend radius if necessary, to work in very tight installations.

Clear Color. The S45-B003 strain reliefs come in a clear color so that it easily works with all cable jacket colors.

Snagless Design. The S45-B003 strain reliefs are a snagless design. This prevents broken latch tabs on the RJ45 modular plugs.

Wide Mouth Resealable Bag for Easy Hand Access. No need to spill RJ45 mod plugs out of the bag just to reach them. The S45-B003 strain reliefs bag packaging stands up and can remain open so that you can easily reach in and remove the strain reliefs.

PROSeries Strain Relief with RED Locking Pin for all Simpy45® UTP Cat6/Cat6A RJ45 - 100pcs/bag

Simply45® strain relief boots with red locking pin will greatly reduce truck roll backs from tampering with network connections and accidental disconnections. Strain reliefs prevent excessive bending or twisting of the cable near the connector, reducing the risk of damage to the internal wires and ensuring a longer lifespan for the cable. Simply45® strain reliefs are the same width as the RJ45 connector body and becomes integrated into the RJ45 plug during the crimping process. The extended tab provides a snag proof protection for the locking tab on the plug. Adding strain reliefs is a cost-effective way to ensure the longevity and reliability of your network connections.

The Simply45® S45-B002P – Integrated Snagless Strain Reliefs lock into the RJ45 modular plug so that both the plug and strain relief can be permanently attached to the Simply45® RJ45 modular plug during the crimping cycle.

The Simply45® S45-B002P strain reliefs extend the useful life of the RJ45 modular plug termination and should be used with all terminations. It is also Fast and Easy to Use.

NOTE: The S45-B002P is designed to work with the following Simply45® part numbers: S45-1550, S45-1600/1601; S45-1700/1700P; S45-1100. For Cat5e Unshielded RJ45 modular plugs S45-1500/1501; S45-1000, please use our S45-B001 strain reliefs.

Simply45® S45-B002P Integrated Snagless Strain Reliefs for Cat6/6a and Cat5e Shielded with Internal Ground Features:

Prolongs Life of the Termination. The S45-B002 takes the strain off the terminated plug. When you do not use a strain relief, any contact with the plug or cable puts strain directly on the terminated plug. Over time this could cause one or more of the RJ45 pins to become loose. If a pin becomes loose it will create electrical resistance. Resistance creates heat. This could then cause performance problems or damage to the device socket.

Commercial Rated UL94 V0. The Simply45® S45-B002P RJ45 modular plug strain reliefs are UL94 V0 (IEC 60695-11-10) rated for all commercial installations. These strain reliefs are recommended for CMP Plenum, CMR, CM; and LSZH up to B2ca rated LAN cables.

Narrow Design for Easy Access. The S45-B002P strain reliefs are the same width as the RJ45 modular plug. Most common strain reliefs slide over the RJ45. This makes the terminated connector much wider and difficult to use in multi-port patch panels and devices. Therefore, many installers decide to forgo using strain reliefs. The Simply45® S45-B002P strain reliefs lock into the plug during the termination and maintain a very narrow profile. This allows easy access to the plug in these tight installations.

Maintains Correct Bend Radius of the Termination. The Simply45® S45-B002P Integrated Strain Reliefs protect the terminated RJ45 from damage during the life of the link or channel. Maintaining industry standards bend radius is important for maximizing the link/channel performance.

Professional Finish. In addition to protecting the termination and extending the operating life of the link/channel, the S45-B002P strain reliefs also provide a professional finish to your terminated RJ45.

Trimmable. The S45-B002P strain reliefs are trimmable so that you can adjust the bend radius if necessary to work in very tight installations.

Clear Color. The S45-B002P strain reliefs come in a clear color so that it easily works with all of the Simply45® RJ45 modular plugs indicated above.

Snagless Design. The S45-B002P strain reliefs are a snagless design. This prevents broken latch tabs on the RJ45 modular plugs.

Wide Mouth Resealable Bag for Easy Hand Access. No need to spill RJ45 mod plugs out of the bag just to reach them. The S45-B002P strain reliefs bag packaging stands up and can remain open so that you can easily reach in and remove the strain reliefs.

PoE/PoH Rated. The S45-B002P strain reliefs are ideal for PoE/PoH applications. They are Commercial Rated UL94 V0 to match their RJ45 modular plugs.

PROSeries Pass Through Red Tint, Hi/Lo Stagger - Cat6/6a UTP with Cap45™ - 50pc Clamshell

Simply45® ProSeries hybrid connectors feature our patented Cap45. The ProSeries connector provides the convenience of a pass-through style with the security of a standard modular plug. Simply45® only uses the highest quality materials to ensure reliable results and will greatly reduce truck rollbacks. Our connectors are commercially rated and feature a 3-prong style contact designed for all PoE applications, making Simply45® ProSeries the most reliable terminations on the market today.

Simply45® ProSeries Unshielded Pass Through RJ45 Modular Plugs with Cap45® for 23AWG Solid (Cat6/6a UTP), Hi/Lo Stagger, Wire Conductors 1.05mm-1.2mm/0.041″-0,047″, Max Cable OD 7.4mm/0.0291″, UL94 V0 Commercial Rated, Red Tint- 50pc/Clamshell

Simply45® the industry-leading brand for RJ45 modular plug innovation and performance solutions introduces our ProSeries Pass-Through RJ45 Modular Plug, S45-1700P for unshielded LAN cables. This exclusive patented pass-through RJ45 modular plug is a historic breakthrough in “pass-through” RJ45 reliability and performance.

The Simply45® ProSeries introduces the exclusive Cap45® (PATENT 10,811,831 B1). Cap45® is an isolation cap/bar that snaps onto the front of the pass-through RJ45 plug after termination, covering the exposed wire ends. Cap45® prevents electrical shorting in the RJ45 socket due to improperly trimmed wires or device sockets that may not be 100% compliant. With Cap45®, any electrical risks associated with exposed wire ends are now eliminated completely.

Cap45® is a MUST-HAVE for all pass-through RJ45 modular plugs used in commercial and certified system terminations.

PROSeries Pass Through 1 Piece Shielded External Ground Green Tint - Cat6 STP with Bar45™ & Cap45™ - 50pc Jar

Simply45® ProSeries hybrid connectors feature our patented Cap45. The ProSeries connector provides the convenience of a pass-through style with the security of a standard modular plug. Simply45® only uses the highest quality materials to ensure reliable results and will greatly reduce truck rollbacks. Our connectors are commercially rated and feature a 3-prong style contact designed for all PoE applications, making Simply45® ProSeries the most reliable terminations on the market today.

Simply45® the industry-leading brand for RJ45 modular plug innovation and performance solutions introduces our ProSeries Shielded with External Ground Pass-Through RJ45 Modular Plug, S45-1650P. The uniquely designed and patented Simply45® ProSeries S45-1650P simplifies and improves the terminated plug performance for shielded Cat6 and Cat6A F/UTP LAN cables. The Simply45® ProSeries S45-1650P Pass-Through RJ45 modular plugs are by far the highest performing, easiest to use, and most cost-effective way to professionally terminate Cat6 Shielded STP and Cat6A F/UTP LAN cables.

Simply45® introduces our ProSeries Pass-through RJ45 Modular Plugs with our exclusive Cap45® (PATENT: 10,811,831 B1). Cap45® quickly and easily snaps onto the front of the plug covering the exposed wire ends. No risk of electrical shorting due to improperly trimmed wire ends. Simply45® ProSeries is the right solution for commercial networking, certified systems, HDBaseT, PoE/PoH, and all professional installations.

Cap45® is a must-have for all pass-through RJ45 modular plugs used in commercial and certified system terminations.

PROSeries Pass Through 1 Piece Shielded External Ground Green Tint - Cat6 STP with Bar45™ & Cap45™ - 25pc Clamshell

Simply45 PROSeries Shielded Pass Through 1 piece RJ45 Modular Plugs with Bar45™ & Cap45™ for 23AWG Solid (Cat6/6a STP), Hi/Lo Stagger, Wire Conductors 1.05mm-1.2mm/0.041″-0,047″, Max Cable OD 7.4mm/0.0291″, UL94 V0 Commercial Rated, Green Tint

Pass Through Cat6 UTP, Green Tint - 20pcs/Bag

Simply45 Unshielded Pass Through RJ45 Modular Plugs for 23AWG Solid (Cat6 UTP), 26-24AWG Stranded (Cat5e/6 UTP), Wire Conductors 0.95mm-1.05mm/0.037″-0.041″, Max Cable OD 7.0mm/0.276″, UL94 V0 Commercial Rated, Green Tint

PROSeries Pass Through Green Tint - Cat6 UTP with Cap45™ - 50pc Clamshell

Simply45® ProSeries hybrid connectors feature our patented Cap45. The ProSeries connector provides the convenience of a pass-through style with the security of a standard modular plug. Simply45® only uses the highest quality materials to ensure reliable results and will greatly reduce truck rollbacks. Our connectors are commercially rated and feature a 3-prong style contact designed for all PoE applications, making Simply45® ProSeries the most reliable terminations on the market today.

The Simply45® ProSeries introduces the exclusive Cap45® (PATENT 10,811,831 B1). Cap45® is an isolation cap/bar that snaps onto the front of the pass-through RJ45 plug after termination, covering the exposed wire ends. Cap45® prevents electrical shorting in the RJ45 socket due to improperly trimmed wires or in device sockets that may not be 100% compliant. With Cap45®, any electrical risks associated with exposed wire ends are now eliminated completely.

Cap45® is a MUST-HAVE for all pass-through RJ45 modular plugs used in commercial and certified system terminations.

PROSeries Pass Through Shielded - Cat5e STP (internal ground) With Cap45™- 50pc Clamshell

Simply45® ProSeries hybrid connectors feature our patented Cap45. The ProSeries connector provides the convenience of a pass-through style with the security of a standard modular plug. Simply45® only uses the highest quality materials to ensure reliable results and will greatly reduce truck rollbacks. Our connectors are commercially rated and feature a 3-prong style contact designed for all PoE applications, making Simply45® ProSeries the most reliable terminations on the market today.

Simply45 ProSeries Shielded Internal Ground Pass Through RJ45 Modular Plug with Cap45 for 24AWG Solid (Cat5e STP), 28-26AWG Stranded (Cat5e/6/6a STP), Wire Conductors 0.95 – 1.05mm/ 0.037″ – 0.041″, Max Cable OD 6.5mm/0.255″, UL94 V0 Commercial Rated, Blue Tint

Pass Through Cat5e UTP, Blue Tint - 20pcs/Bag

Simply45 Unshielded Pass Through RJ45 Modular Plugs for (Cat5e UTP) Solid 24AWG, (Cat5e/6) Stranded 28-26AWG, Wire Conductors 0.95 – 1.05mm/ 0.037″ – 0.041″, Max Cable OD 6.5mm/0.255″, UL94 V0 Commercial Rated, Blue Tint

PROSeries Pass Through Blue Tint - Cat5e UTP with Cap45™ - 50pc Clamshell

Simply45® ProSeries hybrid connectors feature our patented Cap45. The ProSeries connector provides the convenience of a pass-through style with the security of a standard modular plug. Simply45® only uses the highest quality materials to ensure reliable results and will greatly reduce truck rollbacks. Our connectors are commercially rated and feature a 3-prong style contact designed for all PoE applications, making Simply45® ProSeries the most reliable terminations on the market today.

Simply45® is the industry-leading brand for RJ45 modular plug innovation and performance solutions. *Our S45-1501P is the same as our S45-1500P except is packaged in a convenient 50-piece plastic clamshell.

The Simply45® ProSeries introduces the exclusive Cap45® (PATENT 10,811,831 B1). Cap45® is an isolation cap/bar that snaps onto the front of the pass-through RJ45 plug after termination, covering the exposed wire ends. Cap45® prevents electrical shorting in the RJ45 socket due to improperly trimmed wires or in device sockets that may not be 100% compliant. With Cap45®, any electrical risks associated with exposed wire ends are now eliminated completely.

Cap45® is a MUST-HAVE for all pass-through RJ45 modular plugs used in commercial and certified system terminations.

Standard Cat7a/7/6a Shielded External Ground RJ45 Modular Plugs with Bar45™ Orange Tint, Hi/Lo Stagger - 50pcs/Jar

Simply45 Standard Series connectors feature our reengineered connector designed for the technology used today. Simply45 only uses the highest quality materials to ensure reliable results that greatly reduce truck roll backs. Our connectors are commercial rated and feature a 3 prong style contact designed for all PoE application making Simply45 the most reliable RJ45 termination on the market today.

Up until now, using an RJ45 modular plug to terminate shielded 10G LAN cables such as Cat7a, Cat7 and Cat6a were time-consuming, and frustrating, and if you ever put a Fluke test on longer distance links or channels, the results were not exactly stellar. Of course, you could use an industrial-style RJ45 Field Plug connector, but those are expensive and still require more effort than they should. The Simply45® engineering team did extensive testing and development to design a high-performing Standard WE/SS (8P8C) RJ45 modular plug solution that was both easy to use and cost-effective.

Introducing our S45-1155 Standard WE/SS Shielded with External Ground RJ45 Modular Plugs for 10G LAN cables with FPE insulated wires. FPE (foam polyethylene) insulated wires are found on most of today’s 10G Shielded LAN such as Cat7a, Cat7, Cat6a with S/FTP, U/FTP, and F/FTP LAN cable constructions. The S45-1155 are IEEE 802.3 10GBase-T compliant.

Note: If you are using a larger diameter shielded LAN cable with PE (solid polyethylene) we recommend using the S45-1150 Standard RJ45 modular plug or the Simply45® ProSeries Pass-Through part S45-1755P.

The uniquely designed Simply45® S45-1155 simplifies and improves the terminated plug performance for shielded 10G LAN cables. The S45-1155 shielded modular plugs are by far the highest performing, easiest to use, and most cost-effective way to professionally terminate 10G Shielded LAN cables with FPE insulated wires.

Standard Shielded (External Ground) Cat6 STP RJ45 Modular Plugs with Bar45™ Green Tint, Hi/Lo Stagger - 50pcs/Jar

Simply45 Standard Series connectors feature our reengineered connector designed for the technology used today. Simply45 only uses the highest quality materials to ensure reliable results that greatly reduce truck roll backs. Our connectors are commercial rated and feature a 3 prong style contact designed for all PoE application making Simply45 the most reliable RJ45 termination on the market today.

Simply45® is the industry-leading brand for RJ45 modular plug innovation and performance solutions. Introducing the Simply45® S45-1150 Standard WE/SS (8P8C) Shielded with External Ground RJ45 Modular Plug for PE Insulated Wire Conductors such as found on Cat6 Shielded STP and Cat6a F/UTP LAN cables.

The Simply45® S45-1150 RJ45 shielded modular plug provides better signal isolation and terminated performance than other shielded RJ45 modular plugs for larger diameter Shielded LAN cables using PE (solid polyethylene) insulated wire conductors.

Note: If you are using shielded 10G LAN cables with FPE (foamed polyethylene) insulated wire conductors we recommend using the S45-1155 Standard WE/SS RJ45 modular plug or the S45-1755P Shielded Pass-Through RJ45 modular plug for 10G LAN cables.

Standard Shielded (Internal ground) Cat5e STP RJ45 Modular Plugs, Blue Tint - 50pcs Clamshell

Simply45 Standard Series connectors feature our reengineered connector designed for the technology used today. Simply45 only uses the highest quality materials to ensure reliable results that greatly reduce truck roll backs. Our connectors are commercial rated and feature a 3 prong style contact designed for all PoE application making Simply45 the most reliable RJ45 termination on the market today.

Standard Cat5e RJ45 Modular Plugs, Blue Tint - 20pcs/Bag

Simply45 Unshielded Standard WE/SS (8P8C) RJ45 Modular Plugs for 24AWG (Cat5e UTP) Solid, 28-24AWG (Cat5e/6 UTP) Stranded, Wire Conductors 0.95 -1.05mm/0.037″-0.041″, Max Cable OD 6.4mm/0.252″, UL94 V0 Commercial Rated, Blue Tint

EZ-RJ45 Cat5E RJ45 Strain Relief Boots 50pk

The innovative Snag Proof Strain Relief is designed specifically to be crimped with the EZ-RJ45® plugs. Two Patent Pending versions are offered for both the Cat5/5e and the Cat6 plugs. The primary strain relief of the plug locks the snag proof strain relief in place so they will not pull off, creating one, integral assembly. Once crimped, this design allows the plug's primary strain relief to relax slightly, preventing the cable pairs from being over compressed. This decrease in stress contributes to achieving peak performance. The tab on the strain relief is designed to extend over the plug's locking tab, making it snag proof when administering patch cords.

Application

Maintain bend radiuses, especially on stranded cable. For an installation that requires a professional & finished look.

Platinum Tools Cat6 RJ45 EZ-RJ45 Connector 100 Pack

As anyone who has ever planned their network knows, terminating Ethernet cables isn’t necessarily hard. It can be a tedious process, though, and it is critical to speed and functionality to get it correct. If you have a lot of cables to connect or if you’re a network professional, the amount of time spent on getting conductors just right can be frustrating and even wasteful. You have to measure carefully to ensure you are clipping the precise length of wire to fit snugly into your connector and often you have to assume your pins have stayed in the right order before you crimp them.

Platinum Tools, a leading designer, and manufacturer of network wiring instruments, has created a patented EZ system to eliminate many of the headaches associated with those tiny connectors. Product number 100010B is a 100-pack of Cat6 EZ-RJ45 connectors. These connectors can be used with most ordinary crimpers, but the full benefits can only be experienced when used with an EZ-RJ45 crimp tool.

The Difference

The initial steps for adding an EZRJ45 connector onto a Cat6 Ethernet cable is the same. You score the outer jacket and remove an inch and a half, snipping the pull thread to get it out of your way once you have enough of the conductors exposed. Untwist the pairs and line them up according to your chosen wiring diagram. Then, instead of measuring where you need to snip off the excess wire, you skip straight to inserting the cable into the connector. Thanks to the all-transparent pull-through design, you can quickly check to make sure the correct wire pin-out has been maintained by checking the wires that have come out the end of the connector and by looking into the body of the connector itself. Once everything is lined up properly, crimp the connector on. The EZ-RJ45 tool will crimp and cut away the extra wire all in one squeeze.

Platinum Tool Cat6 ezEX™44 ezEX-RJ45® Connector

The Platinum Tools 202044J Cat6 ezEX™44 ezEX-RJ45® Connector is manufactured to provide easy termination when crimped onto Cat6 structured cabling. The unique design makes it easy to verify wiring sequences before terminating and allows larger conductors to pass through the front end. The integrated Hi-Lo stagger load bar isolates each conductor for higher performance.

ezEX™44 - ezEX-RJ45® connectors are made in the USA with high quality, American-made workmanship. This 100 pack comes in a resealable plastic jar for easy storage and portability.

These connectors are designed for use with the EXO™ Crimp Frame and EXO-EX Die (100061C).

Package Includes

• (100) Platinum Tools ezEX™44 - ezEX-RJ45® Connectors in Plastic Jar

Platinum Tools Cat6 EZ-RJ45 Strain Relief  50 Pack

Platinum Solutions

As anyone who has ever planned their network knows, terminating Ethernet cables isn’t necessarily hard. It can be a tedious process, though, and it is important to speed and functionality to get it correct. If you have a lot of cables to connect or if you’re a network professional, the amount of time spent on getting conductors just right can be frustrating and even wasteful.

Platinum Tools, a leading designer and manufacturer of network wiring instruments, has created a patented EZ system to eliminate many of the headaches associated with those tiny connectors. Product number 100036 is a 50-pack of EZ-RJ45 Cat6 strain-relief boots. These boots can only be used with EZ-RJ45 Cat6 connectors. When used with a connector, they help protect the cable from snags and relieve stress from bends and pressure.

The Difference

The initial steps for adding an EZ-RJ45 connector onto an Ethernet cable is the same. Slide the 100036 strain relief boot onto the cable as soon as you slip off the length you want. The unique design of these boots locks to the EZ-RJ45 end for easy all-at-once connections. Remove an inch and a half of the jacket. Untwist the pairs and line them up according to your chosen wiring diagram. Then insert the cable into the EZ-RJ45 connector, which is sold separately. Thanks to the all-transparent pull-through design, you can quickly check to make sure the correct wire pinout has been maintained by checking the wires that have come out the end of the connector and by looking into the body of the connector itself. Once everything is lined up properly, crimp the connector on. The EZ-RJ45 tool will crimp and cut away the extra wire all in one squeeze.

Platinum Tools ezEX™48 Shielded CAT6A Connector

This shielded ezEX-RJ45 connector is designed for larger cables and conductors. Features a unique integrated Hi-Lo stagger load bar and allows ‘big’ conductors to pass through the front end of the connector making it easy to verify the wiring sequence before terminating. This connector is typically used with Cat6A and is terminated with EXO Crimp Frame® and EXO-EX Die™ (100061C).

The Vertical Cable 011-020G-100 Cat5E RJ45 Shielded Modular Plug w/ Ground Wire Hook provides extra protection in noisy environments. Gold plated terminal contacts offer corrosion resistance and optimal signal integrity, while shielding protects against EMI and RFI interference. Available in bags of 100 pieces.

Platinum Tools ezEX Starter Kit

The ezEX Starter Kit gives you everything you need to start using Platinum's most advanced connector - the ezEX RJ45®. The kit includes the EXO™ Crimp Frame with EX Die for perfect crimps and clean trims every time, as well as a complete assortment of ezEX connectors and strain reliefs, all at a very special price. The ezEX is the most modern RJ45 connector design that will handle the widest variety of cable sizes while offering Cat5e, Cat6 and Cat6A compatibility at speeds up to 10Gb. It is also the only one-piece connector we make that is certified for use in PoE and PoE+ applications.

Rapid45 Cat5e/6 Connector (50-100 pack)

Rapid45 is proud to bring you a new EZ-style pass-through RJ45 connector at an unmatched value. All the features you demand for your basic data and security installations in one Cat5e/Cat6 compatible connector. And the compact cut, strip & crimp tool makes terminations clean and simple

10G Rated RJ45 Toolless Shielded Field Plug for larger cables- 22-24AWG, 9mm OD- Shielded 1pc for Cat6/6a/7a - 1ea/Bag

10G Rated RJ45 Field Plug for larger cables- 22-24AWG, 9mm OD – Ultra Slim – Fully Shielded 1pc Design for Cat6/6a/7a Shielded LAN cables, Toolless, Re-Usable, ANSI/TIA, ISO/IEC, PoE IEEE 802.3bt
