TP-Link CPE510 5GHz 300Mbps 13dBi Outdoor CPE

SKU#: CPE510

UPC#: 845973070922

60 Day Money Back Guarantee

100% Secure Shopping

SKU#: CPE510

UPC#:845973070922
$64.22

SKU#: CPE510

UPC#:845973070922

SKU#: CPE510

UPC#: 845973070922

60 Day Money Back Guarantee

100% Secure Shopping

Same Day Shipping likely on orders placed in the next 00 hours 00 minutes 00 seconds.

  • Description+
  • TP-LINK’s 5GHz 300Mbps 13dBi Outdoor CPE, the CPE510 is dedicated to cost effective solutions for outdoor wireless networking applications. With its centralized management application, it is flexible and ideal for point-to-point, point-to-multipoint and outdoor Wi-Fi coverage applications.  Professional performance, coupled with user-friendly design, makes CPE510 an ideal choice for both business and home users.

    Enterprise Hardware

    With Qualcomm Atheros enterprise level chipsets, high gain antennas and high quality material, specially designed enclosure, and PoE power supply, CPE510 is specially designed for outdoor use and can operate flawlessly in almost any climate, with operating temperatures ranging from -30? (-22?) to +70 ? (158?).

    Advanced Antenna System

    • Built-in High Gain Dual-Polarized Antenna
    • Dedicated metal reflector ensures higher gain
    • and lower noise interference

    15km+ Wireless Data Transmission

    Specially designed for outdoor uses, ideal for long distance wireless data transmission, covering a range of 15km+ , tested in the field.

    TP-LINK MAXtream TDMA Technology

    As network scale increases, wireless competition and collisions among CPEs and base stations will be
    so enormous that the real throughput of the network will drop, resulting in a serious impact on end-user
    experience. To mitigate these effects, the CPE510 uses MAXtream TDMA Technology.

    Pharos Control – Centralized Management System

    CPE510 also comes equipped with centralized management software that helps users easily
    manage all the devices in their network from a single PC - Pharos Control. Functions like device discovery,
    status monitoring, firmware upgrading, and network maintenance can be managed using Pharos Control.

    PharOS

    User-friendly web-based management system allows professionals to do more specific configurations.



    * Maximum wireless transmission rates are the physical rates derived from IEEE Standard 802.11 specifications. Range and coverage specifications along with the number of connected devices were defined according to test results under normal usage conditions. Actual wireless transmission rate, wireless coverage, and number of connected devices are not guaranteed, and will vary as a result of 1) environmental factors, including building materials, physical objects and obstacles, 2) network conditions, including local interference, volume and density of traffic, product location, network complexity, and network overhead and 3) client limitations, including rated performance, location, connection quality, and client condition.

    ** Protection against lightning and electro-static discharge may be achieved through proper product setup, grounding and cable shielding. Refer to the instruction manual and consult an IT professional to assist with setting up this product.

    *** Power supply distances are based on test results under normal usage conditions. Actual power supply distance will vary as a result of 1) AP status, including transmit power, connected devices and network traffic along with 2) cable properties, including type and texture, and 3) environmental factors, which include temperature and humidity.



  • Features+
    • Built-in 13dBi 2x2 dual-polarized directional MIMO antenna
    • Adjustable transmission power from 0 to 23dBm/200mw
    • System-level optimizations for more than 15km long range wireless transmission
    • TP-LINK Pharos MAXtream TDMA (Time-Division-Multiple-Access) technology improves product performance in throughput, capacity and latency performance, ideal for PTMP applications
    • Centralized Management System – Pharos Control
    • AP / Client / Bridge / Repeater / AP Router / AP Client Router (WISP) operation modes
    • Passive PoE Adapter supports up to 60 meter (200 feet) Power over Ethernet deployment and allows the device to be reset remotely
  • Specs+
  • HARDWARE FEATURES
    Processor Qualcomm Atheros Enterprise 560MHz CPU, MIPS 74Kc
    Memory 64MB DDR2 RAM, 8MB Flash
    Interface 1 10/100Mbps Shielded Ethernet Port (Passive PoE in)
    1 Grounding Terminal
    1 Reset Button
    Power Supply Passive Power over Ethernet via LAN0 (+4,5pins; -7,8pins)
    Voltage range: 16-27VDC
    Power Consumption 10.5 Watts Max
    Note: When deployed using Passive PoE, the power drawn from the power source will be higher by some amount depending on the length of the connecting cable.
    Dimensions ( W x D x H ) 8.8 x 3.1 x 2.4 in
    Antenna Type Built-in 13dBi 2 x 2 Dual-polarized Directional Antenna
    Beam Width: 45° (H-Plane) / 30° (E-Plane)
    Protection 15KV ESD Protection
    6KV Lightning Protection
    Enclosure Outdoor ASA stabilized plastic material
    IPX5 waterproof Certification
    WIRELESS FEATURES
    Wireless Standards IEEE 802.11a/n (with Pharos MAXtream disabled)
    Proprietary Protocol TDMA Mode (with Pharos MAXtream enabled)
    Wireless Speeds Up to 300Mbps (40MHz,Dynamic)
    Up to 144.4Mbps (20MHz,Dynamic)
    Up to 72.2Mbps (10MHz,Dynamic)
    Up to 36.1Mbps (5MHz,Dynamic)
    Frequency 5.15~5.85GHz
    Note: Available operating frequency may vary depending on the limitations of the countries or regions in which the device is used.
    Transmission Power 23dBm/200mw (Adjustable power by 1dBm)
    Note: Maximum transmission power may vary across different channels depending on the limitations of the countries or regions in which the device is used.
    SOFTWARE FEATURES
    Wireless Configurations Pharos MAXtream TDMA Technology
    802.11a/n Modes
    Selectable Channel Width: 5/10/20/40MHz
    Automatic Channel Selection
    Transmission Power Control
    Dynamic Frequency Selection (DFS)
    WDS Enable/Disable
    Security: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption, 64/128/152-bit WEP Encryption
    SSID Broadcast Enable/Disable
    Multi-SSID with VLAN Tagging (AP mode only)
    Distance/ACK Timeout Setting
    Wireless MAC Address Filter
    Wireless Advanced:
    > Beacon Interval/RTS Threshold/Fragmentation
    >Threshold/DTIM Interval/AP Isolation/Short GI/Wi-Fi Multimedia
    Management Discovery and Remote Management via Pharos Control application
    HTTP/HTTPS Web-based management
    System Log
    SNMP Agent(v2c)
    Ping Watch Dog
    Dynamic DDNS
    SSH Server
    System Tools Wireless Signal Quality Indicators:
    Signal Strength/Noise/Transmit CCQ/CPU/Memory
    Monitors: Throughput/Stations/Interfaces/ARP/Routes/WAN/DHCP
    Spectrum Analyzer
    Speed Test
    Ping
    Traceroute
    System-level Optimizations Optimized IGMP Snooping/Proxy for multicast applications
    Hardware watch dog
    POE ADAPTER FEATURES
    Dimensions(W x D x H) 4.3 x 2.2 x 1.3 in
    Interfaces 1 AC Jack with Earth Ground
    1 10/100Mbps Shielded Ethernet Port (Power + Data)
    1 10/100Mbps Shielded Ethernet Port (Data)
    Button Remote Reset Button
    Power Status LEDs Green
    Input 100-240VAC, 50/60Hz
    Output 24VDC, 1A Max
    +4, 5pins; -7, 8pins. (Support up to 60m Power over Ethernet)
    Efficiency >80%
    Certifications CE/FCC
    OTHERS
    Certification FCC, RoHS, IPX5
    System Requirements Google Chrome, Safari, and Firefox browsers for web GUI management
    Environment Operating Temperature: -30°C~70°C (-22?~158?)
    Storage Temperature: -40?~70? (-40?~158?)
    Operating Humidity: 10%~90% non-condensing
    Storage Humidity: 5%~95% non-condensing
  • Package Contents+
    • Outdoor Wireless CPE
    • 24V 1A Passive PoE Adapter
    • Pole Mounting Straps
    • AC Power Cord
    • Installation Guide
