- Description+
- EAP245 V3.0
- Features+
- Gigabit network ports
- 48VDC passive PoE injector
- Auto-detect and auto-supply the necessary power required
- Plug-and-Play, requires no configuration
- Specs+
- Package Contents+
- 48V, 24W Passive PoE Adapter TL-POE4824G
- Power Cord
- Wall Mounting Kits
- Reviews+
- EAP245 V3.0
- Gigabit network ports
- 48VDC passive PoE injector
- Auto-detect and auto-supply the necessary power required
- Plug-and-Play, requires no configuration
- 48V, 24W Passive PoE Adapter TL-POE4824G
- Power Cord
- Wall Mounting Kits
Passive PoE Adapter
Powers TP-Link products that support 48V passive PoE, TL-POE4824G
Power Your Devices
Use the passive PoE adapter TL-POE4824G to simultaneously supply power and transmit data to a passive PoE device.
Convenient Wall-Mounting Design
TL-POE4824G offers a convenient wall-mounting brackets to be easily installed on a wall.
Compatible Devices
TL-POE4824G is recommended to offer power supply to TP-Link’s passive PoE products which as follows.
| HARDWARE FEATURES | |
|---|---|
| Interface | 2 x 10/100/1000Mbps RJ45 Port Auto Negotiation/Auto MDI/MDIX 1 x 48VDC PoE port |
| Network Media | 10BASE-T: UTP category 3, 4, 5 cable (Max 100m) EIA/TIA-568 100Ω STP (Max 100m) 100BASE-TX: UTP category 5, 5e cable (Max 100m) EIA/TIA-568 100Ω STP (Max 100m) 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100m) |
| LED Indicator | PWR |
| Dimensions ( W x D x H ) | 4.3 × 2.3 × 1.5 in. (110×57×38.8 mm) |
| OTHERS | |
|---|---|
| Certification | FCC, RoHS |
| Environment | Operating Temperature: 0?~40? (32?~104?) Storage Temperature: -40?~70? (-40?~158?) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
Passive PoE Adapter
Powers TP-Link products that support 48V passive PoE, TL-POE4824G
Power Your Devices
Use the passive PoE adapter TL-POE4824G to simultaneously supply power and transmit data to a passive PoE device.
Convenient Wall-Mounting Design
TL-POE4824G offers a convenient wall-mounting brackets to be easily installed on a wall.
Compatible Devices
TL-POE4824G is recommended to offer power supply to TP-Link’s passive PoE products which as follows.
| HARDWARE FEATURES | |
|---|---|
| Interface | 2 x 10/100/1000Mbps RJ45 Port Auto Negotiation/Auto MDI/MDIX 1 x 48VDC PoE port |
| Network Media | 10BASE-T: UTP category 3, 4, 5 cable (Max 100m) EIA/TIA-568 100Ω STP (Max 100m) 100BASE-TX: UTP category 5, 5e cable (Max 100m) EIA/TIA-568 100Ω STP (Max 100m) 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100m) |
| LED Indicator | PWR |
| Dimensions ( W x D x H ) | 4.3 × 2.3 × 1.5 in. (110×57×38.8 mm) |
| OTHERS | |
|---|---|
| Certification | FCC, RoHS |
| Environment | Operating Temperature: 0?~40? (32?~104?) Storage Temperature: -40?~70? (-40?~158?) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
