DIN-Rail Modular LGX Optic Fiber Cassette
DIN-Rail Modular LGX Optic Fiber Cassette, Mountable universal cassette, compatible with standard LGX-format adapter plates
Supplied as a kit:
Bay x 1, Cassette x 1, FM stage x 1, DIN-Rail Clip x 1, Blank cable entry adapter x 1, Medium grommet cable entry adapter x 1, Identification label x 1, Cable Tie x 2.
Each unit is recommended to be ordered with a choice of two cable entry adapters (see accessories below), which provide specific options for cable entry, fixation, or connection.
The 268-EZM01-1A-05 is a DIN-rail modular cassette designed for fiber termination in industrial control panels, automation systems, and equipment enclosures. This din-rail modular cassette accommodates one LGX adapter plate supporting up to 24 optical fibers or up to 6 keystone modules, providing flexible connectivity options directly on standard 35-mm DIN-rail.
APPLICATIONS
The 268-EZM01-1A-05 DIN-rail modular cassette excels in industrial and commercial fiber termination scenarios:
-
Industrial Control Panels: Mount directly alongside PLCs, VFDs, and automation equipment for fiber connectivity in manufacturing environments.
-
Building Automation Systems: Terminate fiber connections for BMS, HVAC controls, and building management networks.
-
Process Control: Provide reliable fiber termination in harsh industrial environments including factories, refineries, and processing plants.
-
Transportation Infrastructure: Deploy in rail, transit, and traffic control systems where DIN-rail mounting is standard.
-
Data Centers: Install in equipment racks and cabinets where DIN-rail infrastructure is utilized for fiber distribution.
WHY CHOOSE THE 268-EZM01-1A-05 DIN-RAIL MODULAR CASSETTE?
Professionals choose the 268-EZM01-1A-05 because it brings professional fiber termination directly into industrial control environments. Here are 5 reasons to specify it for your next project:
-
True Industrial Integration – Mounts on standard 35-mm DIN-rail alongside PLCs, terminal blocks, and automation equipment for unified panel design.
-
Fiber and Copper Ready – Accepts LGX adapter plates for fiber or keystone modules for copper, providing true hybrid connectivity.
-
Modular Serviceability – Separate bay and cassette design allows easy access for maintenance, testing, and reconfiguration without disturbing adjacent equipment.
-
Comprehensive Splice Support – Accommodates up to 24 fusion splices with removable fiber management stage for organized terminations.
-
Standards Compliant – Meets IEC/EN 60715, DIN 43880, ANSI/TIA-568.3-D, and GR-769 for assured compatibility in industrial and telecom applications.
WHAT’S NEXT?
Once you’ve specified the 268-EZM01-1A-05 for your project:
-
Select Your Adapter Plate – Choose the appropriate 264-MAP or 264-LAP Series LGX adapter plate for your connector type, or configure with keystone modules.
-
Plan DIN-Rail Space – Ensure adequate DIN-rail length (35 mm width) and clearance depth (150 mm) in your control panel or enclosure.
-
Plan Splice Requirements – If splicing is needed, add 265-HLD01-2B-00 splice holders and 265-SLV01 splice protection sleeves.
-
Test After Installation – Verify optical continuity and insertion loss after termination is complete.
$42.61
×
